Kubota U35-4HG Excavator

The Kubota U35-4HG Tight Tail Swing Compact Excavator combines powerful digging performance, excellent attachment versatility and an open ROPS canopy for outstanding visibility and easy access. Its compact 3.5-tonne design makes it ideal for construction, landscaping, utility work and excavation in confined areas.

Powered by a reliable Kubota D1703M-DI-E4 direct-injection diesel engine producing 24.8 gross horsepower, the U35-4HG delivers smooth, efficient performance with a maximum digging depth of 9 feet 8.9 inches and a maximum dumping height of 11 feet 0.7 inches.

The open ROPS/OPG canopy provides excellent visibility around the machine while giving the operator plenty of room to work. A weight-adjustable suspension seat, ergonomic wrist rests, pilot-operated controls and a retractable seat belt help reduce fatigue during extended operation.

The standard AUX1 diverter valve allows auxiliary oil to be redirected to another hydraulic attachment without disconnecting the thumb piping. Adjustable proportional auxiliary flow, a third-line hydraulic return and a maximum auxiliary flow of 15.8 GPM provide the versatility needed to operate breakers, augers, brush cutters and other hydraulic attachments.

The Kubota U35-4HG Excavator is available from Kooy Brothers Equipment Ltd., located at 1919 Wilson Avenue in Toronto, Ontario.

Contact Us for pricing, availability and additional information.

Features

• Open ROPS/OPG canopy – Provides operator protection, excellent jobsite visibility and convenient entry and exit.

• Tight tail swing design – The counterweight extends only 1.9 inches beyond the tracks, improving manoeuvrability and helping protect the machine when working near buildings and other obstacles.

• Kubota direct-injection diesel engine – The 24.8-horsepower Kubota engine delivers dependable digging and lifting performance while minimizing fuel consumption, noise and vibration.

• Comfortable operator station – Includes a weight-adjustable full-suspension seat, retractable seat belt, adjustable wrist rests and ergonomically positioned pilot controls.

• Digital control panel – Clearly displays engine speed, fuel level, coolant temperature, operating hours, service information and machine alerts.

• Adjustable auxiliary flow – Operators can program up to five AUX1 flow settings for different hydraulic attachments directly through the digital control panel.

• AUX1 diverter valve – Allows auxiliary oil to be redirected to another attachment without removing the hydraulic thumb piping.

• Third-line hydraulic return – Routes oil directly back to the hydraulic tank when operating one-way attachments, helping reduce back pressure and improve hydraulic efficiency.

• Proportional auxiliary control – A bi-directional rocker switch and full-flow button on the right control lever provide precise attachment operation.

• Auto-idle system – Automatically reduces engine speed when the control levers remain in neutral for more than four seconds, helping save fuel and reduce noise.

• Two-speed travel with auto-shift – Automatically shifts between high and low travel speeds based on traction and terrain.

• Variable-displacement hydraulic pumps – Provide smooth, precise control of the boom, arm and bucket while delivering strong breakout performance.

• Dozer blade with float function – Allows the blade to follow the ground contour for faster grading, backfilling and finishing work.

• Two-pattern selection system – Allows the operator to switch between ISO and SAE control patterns.

• Travel and swivel negative brakes – Automatically hold the tracks and upper structure in position to help prevent unintended movement.

Specifications

• Engine model: Kubota D1703M-DI-E4

• Engine type: Three-cylinder, liquid-cooled, direct-injection diesel

• Gross engine output: 24.8 HP (18.5 kW) at 2,200 RPM

• Net engine output: 23.9 HP (17.8 kW) at 2,200 RPM

• Engine displacement: 100.5 cu. in. (1,647 cc)

• Operating weight with rubber tracks: 8,129 lb (3,687 kg)

• Operating weight with steel tracks: 8,325 lb (3,776 kg)

• Maximum digging depth: 9 ft. 8.9 in. (2,970 mm)

• Maximum vertical digging depth: 6 ft. 7.3 in. (2,013 mm)

• Maximum digging height: 15 ft. 10.7 in. (4,844 mm)

• Maximum dumping height: 11 ft. 0.7 in. (3,370 mm)

• Maximum digging radius at ground: 16 ft. 11.3 in. (5,165 mm)

• Maximum digging radius: 17 ft. 3.6 in. (5,272 mm)

• Bucket breakout force: 7,924 lb (3,594 kgf)

• Arm breakout force: 4,451 lb (2,019 kgf)

• Maximum auxiliary hydraulic flow: 15.8 GPM (60 L/min)

• Travel speed: 1.9 mph low / 2.9 mph high (3.0/4.6 km/h)

• Maximum traction force: 6,091 lb (2,763 kgf)

• Swing speed: 8.9 RPM

• Boom swing: 71° left / 45° right

• Overall length: 15 ft. 7 in. (4,749 mm)

• Overall width: 5 ft. 6.9 in. (1,700 mm)

• Overall height: 8 ft. 1.2 in. (2,470 mm)

• Minimum ground clearance: 11.34 in. (288 mm)

• Crawler length: 6 ft. 10 in. (2,084 mm)

• Track width: 11.8 in. (300 mm)

• Blade width: 5 ft. 6.9 in. (1,700 mm)

• Fuel capacity: 12.4 US gal. (46.9 L)

• Hydraulic oil capacity: 11.8 US gal. reservoir / 16.1 US gal. system (44.6/61 L)

Specifications, attachments and standard or optional equipment may vary. The U35-4HG is the open-canopy, standard-blade configuration. Contact Kooy Brothers for complete machine details.
