Kubota SZ22-48-2 Zero Turn Stand-on Mower

Kubota SZ22-48-2 Zero Turn Stand-on Mower is a stand-on zero-turn mower designed for commercial turf work and efficient movement between mowing areas. Kubota lists engine gross power at 16.4 kW / 22 HP, cutting width at 1219.2 mm / 48 in, and mower deck depth at 120.7 mm / 4.8 in. Commercial-grade Kawasaki engines provide power for professional mowing applications.

Contact our team at Kooy Brothers Equipment Ltd. in Toronto, Ontario for current availability, compatible options and a quote.

Features

• Mowing made Easy: Conveniently designed to make mowing a breeze. The operator platform easily folds away giving operators the option to either ride or walk behind while mowing.
• Power: Powered by commercial-grade Kawasaki engines, each Kubota SZ series stand-on mower is primed to deliver effective on the job capability.
• Durable DNA: The SZ series is built for tough commercial-grade mowing demands.
• Quick and nimble: Enjoy agility and speed in one package.
• Mow it your way: The SZ series come with an adjustable reference bat and dampers to give operators a personalized experience.
• Compact and convenient: Thanks to its small footprint, the SZ series is easy to trasnport, store and load on a trailer.

Specifications

Model

• Model name: SZ22-48-2

Engine

• Model: FX691V
• Type: Gasoline, Air-Cooled V-Twin
• Displacement: 726 cc / 44.3 cu. in.
• Manufacturer: Kawasaki
• Engine gross power: 16.405 kW / 22 HP

Dimensions and weight

• Ground clearance: 107.95 mm / 4.25 in
• Overall height: 1162.05 mm / 45.75 in
• Overall length: 1619.25 mm / 63.75 in
• Wheelbase: 1168.4 mm / 46 in
• Without mower: 1228.725 mm / 48.375 in
• With mower: 437.7 kg / 965 lb

Fuel system

• Fuel type: Gasoline

Tires

• Front: 13 x 5-6 (Flat-Free)
• Rear: 23 x 8.5-12

Drive train/transmission

• Type: Hydro-Gear ZT3400

Traveling speed

• Forward: 16.9 km/h / 10.5 mph
• Reverse: 6.4 km/h / 4 mph

Power take off (PTO)

• Clutch: Electric
• Drive system: Belt

Mower decks

• Mower deck depth: 120.65 mm / 4.75 in
• Cutting width: 1219.2 mm / 48 in
• Number of blades: 3
• Cutting height: 114.3 mm / 4.5 in
• Mounting method: Parallel Linkage
• Blade tip speed: 5486.4 m/min / 18000 fpm
• Adjustment of cutting height: Pin
