Kubota BX1880 Sub-Compact Tractor

Kubota BX1880 Sub-Compact Tractor is a sub-compact tractor built for property maintenance, mowing, loader work and three-point implements. Kubota lists engine gross power at 12.4 kW / 16.6 HP, PTO power at 10.2 kW / 13.7 HP, and transmission at HST, High-Low gear shift (2 forward / reverse). The compact footprint provides easy operation and maneuverability in tight spaces while remaining gentle on finished turf.

Contact our team at Kooy Brothers Equipment Ltd. in Toronto, Ontario for current availability, compatible options and a quote.

Features

• Kubota diesel engine: Built with world-leading technology, the Kubota BX80 series boasts a durable 3-cylinder diesel engine, meticulously engineered for lasting performance.
• Year-round versatility: The ultimate jack-of-all-trades, the BX80 Series adapts effortlessly with Kubota’s Swift-Tach loader and K-Connect hitch system, making attachment changes quick and easy.
• Compact and mighty: The compact footprint provides easy operation and maneuverability in tight spaces while remaining gentle on finished turf.
• All-day comfort: Experience unmatched comfort with the BX80’s deluxe high-back seat, designed for all-day support.
• Time-saving K-connect for front implements: The K-Connect four-point hitch couples compatible front implements and their PTO connection from a single lever.
• Intuitive operation: An intuitive interface for smooth, safe, and efficient tractor operation.
• Exceptional ground clearance: Enjoy a generous ground clearance of 7.6 inches for the BX1880 and an even higher 8.4 inches for the BX2380, BX2680, and BX23S models.
• Optional heated cab: Operate the operator's BX-Series in comfort while being protected from the elements.

Specifications

Model

• Model name: BX1880

Engine

• Model: Kubota D722
• Type: Liquid-cooled, 3-cylinder diesel
• Cooling system: Liquid-cooled
• Cylinders: 3
• Rated engine speed: 3200 rpm / 3200 rpm
• Engine gross horsepower @ rpm: 12.4 kW / 16.6 HP
• PTO @ rpm: 10.2 kW / 13.7 HP
• Displacement: 719 cc / 43.9 cu. in.
• Fuel tank capacity: 25 l / 6.6 gal

Power take off (PTO)

• Mid-PTO: Standard
• Rear PTO: Standard
• Type: Live independent PTO (with hydraulic clutch)
• PTO/engine speed: 540 rpm / 540 rpm
• Rated engine speed: 2500 rpm / 2500 rpm

Drive train/transmission

• Transmission type: HST, High-Low gear shift (2 forward / reverse)
• Brake type: Wet disc
• Drive method: 4WD

Hydraulic system

• 3-Point hitch: SAE Category I
• 24" behind lift point: 310 kg / 680 lb
• Total pump output: 23.5 l/min / 6.2 gpm
• Steering type: Hydrostatic Power Steering

Dimensions and weight

• Ground clearance: 193 mm / 7.6 in
• Overall width: 1120 mm / 44.1 in
• Wheelbase: 1400 mm / 55.1 in
• Top of Open Station: 2080 mm / 81.9 in
• With 3 Pt hitch: 2425 mm / 95.5 in
• Front: 930 mm / 36.6 in
• Rear: 820 mm / 32.2 in
• Without brake: 2.3 m / 7.5 ft
• Open Station: 606 kg / 1336 lb

Fuel system

• Fuel type: Diesel

Tires

• Front: 16×7.5– 8
• Rear: 24×12–12
• Front: 16×7.5– 8
• Rear: 24×12–12
• Front: N.A.
• Rear: N.A.

Traveling speed

• Forward: 12.5 km/h / 7.8 mph
• Reverse: 9.5 km/h / 5.9 mph
