Kubota GF1800 Front-Mount Tractor

Kubota GF1800 Front-Mount Tractor is a front-mount mower platform offered in 2WD and 4WD configurations for turf maintenance where visibility and manoeuvrability are important. Drivetrain, dimensions, weight and other model-specific specifications are identified by exact model in the combined Specifications section below.

Contact our team at Kooy Brothers Equipment Ltd. in Toronto, Ontario for current availability, compatible options and a quote.

Features

• Powerful compact lightweight Kubota diesel engine: The 16.6-horsepower diesel engine in each of these front tractors provides high torque rise to handle tough mowing jobs, even in thick grass.
• Kubota HST: The Hydrostatic transmission with cruise control makes mowing smooth and simple with an easy one-foot-pedal operation.
• Hydraulic wet-type multiple-cisc PTO clutch: The hydraulic wet-type multiple-disc PTO clutch is the first in this class.
• Easy maintenance: Attachments are easy to install or remove, and the battery is accessible for routine service.
• Optional attachments: The GF has a variety of different attachments making this front-mount lawn tractor a great choice for those looking utilize their investment year round.

Specifications

Model

• Model name: GF1800E / GF1800

Engine

• Type: Liquid-cooled Diesel Engine
• Cylinders: 3
• Rated engine speed: 3200 rpm / 3200 rpm
• Displacement: 719 cc / 43.9 cu. in.
• Manufacturer: D722
• Engine gross power: 12.4 kW / 16.6 HP
• Mounting method: Damping Rubber Mount

Dimensions and weight

• Overall height: 2030 mm / 79.9 in
• Overall length: 2120 mm / 83.5 in (GF1800E); 2018 mm / 79.4 in (GF1800)
• Overall width: 970 mm / 38.2 in
• Wheelbase: 850 mm / 33.5 in
• 2WD: 355 mm / 13.9 in
• Counter weight: Standard
• Shipping weight (without mower): 570 kg / 1260 lb (GF1800E); 580 kg / 1280 lb (GF1800)
• 4WD: 440 mm / 17.3 in (GF1800)

Fuel system

• Fuel type: Diesel

Other

• Deck type: Semi-flat
• Hour meter: STD on Front Panel
• Water temperature indicator: Meter on Front Panel

Tread

• Front: 724 mm / 28.5 in
• Rear: 775 mm / 30.5 in (GF1800E); 795 mm / 31.3 in (GF1800)

Tires

• Front: 20 × 10 - 8
• Rear: 16 × 6.5 - 8
• Traction: Front Wheel (GF1800E); Front based On-Demand 4WD (GF1800)

Drive train/transmission

• Type: Hydrostatic

Traveling speed

• System: 1 Front Pedal + Cruise Control
• Forward: 13.5 km/h / 8.4 mph
• Reverse: 6.5 km/h / 4.1 mph

Power take off (PTO)

• Clutch: Hydraulic
• PTO brake: Wet Disc

Fluid capacities

• Fuel tank capacity: 20 l / 5.3 gal

Chassis, axle and brakes

• System: Dry internal expanding shoe
• Control type: Rear Wheel
• Type: Manual
• Tilt steering wheel: Standard

Operating area

• Seat adjustment: One touch side
• Fuel tank indicator: on Front Panel
